Atlas Copco GA 5-37 VSDs — Next-Generation Oil-Injected Rotary Screw Air Compressor
The Atlas Copco GA 5-37 VSDs represents the latest evolution in variable speed drive compressor technology. Engineered for maximum energy efficiency and reliability, this compressor delivers up to 60% energy savings compared to traditional fixed-speed models, making it the ideal choice for industrial compressed air applications across Southeast Asia and beyond.
Why Choose GA 5-37 VSDs?
Up to 60% Energy Savings: Advanced VSDs technology automatically adjusts motor speed to match your exact air demand — no wasted energy.
Up to 21% Higher FAD: Compared to previous generation fixed-speed compressors at the same motor power.
Ultra-Quiet Operation: Noise levels as low as 63 dB(A) — quiet enough to install directly on your production floor.
Compact Footprint: Extremely space-efficient design fits where other compressors cannot.
IE5-Ready Motor: FASR motor efficiency equivalent to IE5 standards — exceeding IES2 requirements.
Key Technologies
Feature
Benefit
VSDs Variable Speed Drive
Matches motor speed to air demand in real time for optimal efficiency
Boost Flow Mode
Safely exceeds max capacity during peak demand to prevent production shutdowns
Smart Temperature Control
Full injection control eliminates condensation risk and maximizes efficiency
Elektronikon® Touch
Intuitive multilingual touchscreen controller with advanced monitoring
SMARTLINK Connectivity
Remote monitoring, performance data, and maintenance alerts via smartphone
Neos Next Inverter
Next-generation inverter technology for superior drive efficiency
Technical Specifications
Parameter
Specification
Compressor Type
Oil-injected Rotary Screw
Technology
VSDs (Variable Speed Drive)
Working Pressure Range
4 – 13 bar (58 – 188 psi)
Installed Motor Power
5.5 – 37 kW (7.5 – 50 HP)
Free Air Delivery (FAD)
0.35 – 6.7 m³/min (12.3 – 237 cfm)
Noise Level
As low as 63 dB(A)
Controller
Elektronikon® Touch
Motor Efficiency
IE5 equivalent (FASR motor)
Drive Efficiency
Exceeds IES2 (EN 50598)
Heat Recovery
Up to 80%
Compressor Control
EQ2i integrated (up to 6 compressors with Equalizer 4.0)
Communication Protocol
OPC UA ready
Available Options
Built-in refrigerated dryer (GA+ FF models)
Side-mounted 200L air receiver (GA 5-11 models)
Equalizer 4.0 multi-compressor controller
Multiple voltage configurations for global deployment
Ideal Applications
The GA 5-37 VSDs is perfectly suited for:
Manufacturing facilities & production lines
Automotive workshops & service centers
Food & beverage processing
Textile & garment factories
Pharmaceutical & electronics manufacturing
Construction & mining operations
